S-SERIES · STORAGE
GL-S3U-16H2S
16 × 3.5″ HDD + 2 × 2.5″ SATA/SAS
3U storage server with 16 × 3.5″ HDD + 2 × 2.5″ SATA/SAS bays. Host platform: AMD EPYC 8005/8004. Validated with GenesysBench™ and deployed under GLIDS.
- Memory
- 8 DIMM slots
- Drive bays
- 16× 3.5″ HDD · 2× 2.5″ SATA/SAS
- Height
- 3U
- Sockets
- 1
Specifications
Full public specification.
| Form factor | 3U Rackmount |
|---|---|
| Processor | 1 Socket SP6 (LGA 4844) AMD EPYC™ 8005/8004 series processors |
| Memory | 8 DDR5 288-pin DIMM slots; RDIMM, RDIMM-3DS |
| Expansion | 2 FHHL PCIe5.0 x16 |
| Storage | Front: 16 Hot-swap 3.5" SATA drive bays Rear: 2 Hot-swap 2.5" SATA drive bays2 M-key (PCIe5.0 x4), 22110/2280 form factor |
| Networking | 2 RJ45 (1GbE)1 dedicated IPMI |
| Power | 1+1, 80-PLUS Platinum, 800W CPSU |
| Cooling | 3 PWM Hot-swap 80x38 mm fans |
| Dimensions (D × W × H) | 680 x 430 x 133 mm (26.7" x 16.9" x 5.2") |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
