S-SERIES · STORAGE

GL-S2U-12H2S

12 × 3.5″ HDD + 2 × 2.5″ SATA/SAS

2U storage server with 12 × 3.5″ HDD + 2 × 2.5″ SATA/SAS bays. One chassis, 2 host platforms: AMD EPYC 8005/8004 and AMD EPYC 7002. Validated with GenesysBench™ and deployed under GLIDS.

Memory: 8 DIMM slots
Drive bays: 12× 3.5″ HDD · 2× 2.5″ SATA/SAS
Height: 2U
Sockets: 1

Configure this system Talk to a Solutions Architect

Specifications

Pick the host platform. The chassis, power and cooling follow it.

GL-S2U-12H2S: AMD EPYC 8005/8004 specifications
Form factor	2U Rackmount
Processor	1 Socket SP6 (LGA 4844) AMD EPYC™ 8005/8004 series processors
Memory	8 DDR5 288-pin DIMM slots; RDIMM, RDIMM-3DS
Expansion	2 HHHL PCIe5.0 x16
Storage	Front: 12 Hot-swap 3.5" SATA drive bays Rear: 2 Hot-swap 2.5" SATA drive bays, 7mm height2 M-key (PCIe5.0 x4), 22110/2280 form factor
Networking	2 RJ45 (1GbE)1 dedicated IPMI
Power	1+1, 80-PLUS Platinum, 800W CPSU
Cooling	3 PWM Hot-swap 80x38 mm fans
Dimensions (D × W × H)	680 x 430 x 88 mm (26.7" x 16.9" x 3.5")
Management	Dedicated BMC (IPMI)

Previous generation. Still supported by GLabs; ask a solutions architect about availability.

GL-S2U-12H2S: AMD EPYC 7002 specifications
Form factor	2U Rackmount
Processor	1 Socket SP3 (LGA4094), AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology )/7002 series processors
Expansion	3 PCIe4.0 x16 for FHFL cards 1 PCIe4.0 x8 for FHHL cards 1 OCP2.0 Mezzanine connector A and B (PCIex16)
Networking	2 RJ45 (10GbE) via Intel® X550-AT21 dedicated IPMI
Power	8 DDR4 DIMM slots (1DPC), Supports DDR4 R-DIMM up to 64GB each/ LR-DIMM up to 256GB each; max. 3200MHz1+1, 80-PLUS Platinum, 800W CRPS
Cooling	4 80x38 mm fans
Dimensions (D × W × H)	625 x 430 x 87mm (24.6" x 16.9" x 3.4")
