S-SERIES · STORAGE
GL-S2U-12H
12 × 3.5″ HDD
2U storage server with 12 × 3.5″ HDD bays. Host platform: 3rd Gen Intel Xeon. Validated with GenesysBench™ and deployed under GLIDS.
- Drive bays
- 12× 3.5″ HDD
- Height
- 2U
- Sockets
- 2
Specifications
Full public specification.
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1+1 Socket P+ (LGA4189) for 3rd Gen Intel® Xeon® Scalable Processors |
| Expansion | SLOT1: 2 FHHL PCIe4.0 x16 or1 FHHL PCIe4.0 x16, 2 FHHL PCIe4.0 x8- SLOT2: 2 FHHL PCIe4.0 x16 or1 FHHL PCIe4.0 x16, 2 FHHL PCIe4.0 x8- 1 low-profile PCIe4.0 x16 or 2 low-profile PCIe4.0 x8- |
| Storage | 12 Hot-swap 3.5"/2.5" drive bays, 8 SATA HDD/SSD and 4 NVMe (PCIe4.0 x4) SSD2 Qxed 2.5" SATA drive bays2 M-key (PCIe3.0 x4 or SATA 6Gb/s), 22110/2280 form factor |
| Networking | 2 RJ45 (1GbE)1 dedicated IPMI |
| Power | 1+1 1600W CRPS |
| Cooling | 6 PWM Hot-swap 60x38 mm fans |
| Dimensions (D × W × H) | 770.0 mm X 438.0 mm X 86.4 mm |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
