S-SERIES · STORAGE
GL-S2U-16F
16 × NVMe
2U storage server with 16 × NVMe bays. Host platform: Intel Xeon 6. Validated with GenesysBench™ and deployed under GLIDS.
- Memory
- 32 DIMM slots
- Drive bays
- 16× NVMe
- Height
- 2U
- Sockets
- 2
Specifications
Full public specification.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1+1 Socket E2 (LGA 4710) Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors |
| Memory | 16+16 DIMM slots (2DPC) |
| Expansion | 2 OCP NIC 3.0 (PCIe5.0 / CXL2.0 x16) |
| Storage | 16 Hot-swap E3.S (PCIe5.0 x4) drive bays |
| Networking | 1 dedicated IPMI on DC-SCM 2.0 module |
| Power | 1+1, 80-PLUS Titanium, 2700W RPSU |
| Cooling | 6 PWM Hot-swap 60x56 mm fans |
| Dimensions (D × W × H) | 820 x 438 x 87.5mm (32.3" x 17.2" x 3.4") |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
