S-SERIES · STORAGE
GL-S1U-8F
8 × NVMe
1U storage server with 8 × NVMe bays. Host platform: Intel Xeon 6900P. Validated with GenesysBench™ and deployed under GLIDS.
- Memory
- 12 DIMM slots
- Drive bays
- 8× NVMe
- Height
- 1U
- Sockets
- 1
Specifications
Full public specification.
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 Socket BR (LGA 7592) Intel® Xeon® 6900P-series processors |
| Memory | 12 DIMM slots (1DPC) |
| Expansion | 1 FHHL PCIe5.0 x161 HHHL PCIe5.0 x16 1 OCP NIC 3.0 (PCIe5.0 x16) |
| Storage | Front: 4 Hot-swap E1.S (PCIe5.0 x4) drive bays2 M-key (PCIe5.0 x4), 2280 form factor |
| Networking | 1 dedicated IPMI on DC-SCM 2.0 module |
| Power | 1+1, 80-PLUS Titanium, 1600W CRPS |
| Cooling | 8 fixed 40x56 mm fans |
| Dimensions (D × W × H) | 600 x 438 x 43.5 mm (23.6" x 17.2" x 1.7") |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
