GL-S1U-12H4F
12 × 3.5″ HDD + 4 × NVMe
1U storage server with 12 × 3.5″ HDD + 4 × NVMe bays. One chassis, 3 host platforms: AMD EPYC 9004, 5th / 4th Gen Intel Xeon and AMD EPYC 7003. Validated with GenesysBench™ and deployed under GLIDS.
- Drive bays
- 12× 3.5″ HDD · 4× NVMe
- Height
- 1U
- Sockets
- 1
Specifications
Pick the host platform. The chassis, power and cooling follow it.
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 Socket SP5 (LGA 6096); AMD EPYC™ 9005/9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors |
| CPU TDP | Up to 300W |
| Expansion | 1 FHHL PCIe5.0 x16 (Up to 75W)1 HHHL PCIe5.0 x16 1 OCP NIC 3.0 (PCIe5.0 x16) |
| Storage | 4 hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays12 hot-swap 3.5" SATA drive bays2 M-key (PCIe5.0 x4 or 4 SATA 6Gb/s), 22110/2280/2260 form factor |
| Networking | 2 SFP28 (25GbE)1 dedicated IPMI |
| Power | 1+1, 80-PLUS Platinum, 1000W Slim RPSU |
| Cooling | 6 PWM hot-swap 40x56 mm fans |
| Dimensions (D × W × H) | 955 x 438 x 43.5 mm (37.6" x 17.2" x 17.1") |
| Management | Dedicated BMC (IPMI) TPM (13-pin, SPI) accessory |
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 Socket E (LGA 4677); Supports 5th & 4th Gen Intel® Xeon® Scalable processors |
| Expansion | 1 FHHL PCIe5.0 x161 HHHL PCIe5.0 x16 1 OCP NIC 3.0 (PCIe5.0 x16) |
| Storage | 4 Hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays12 Hot-swap 3.5" SATA HDD drive bays1 M-keyNote1 (PCIe3.0 x4 or SATA 6Gb/s); 22110/2280 form factor1 M-keyNote1 (PCIe3.0 x2 or SATA 6Gb/s); 2280 form factor |
| Networking | 2 SFP28 (25GbE)2 RJ45 (1GbE)1 dedicated IPMI |
| Power | 1+1, 80-PLUS Platinum, 1000W Slim RPSU |
| Cooling | 6 PWM Hot-swap 40x56 mm fans |
| Dimensions (D × W × H) | 955 x 438 x 43.5 mm (37.6" x 17.24" x 1.71") |
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 Socket SP3 (LGA4094), AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology )/7002 series processors |
| Expansion | 1 FHHL PCIe4.0 x8 1 low-profile PCIe4.0 x8 1 OCP NIC 3.0 (PCIe4.0 x16) |
| Storage | 4 Hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays12 Hot-swap 3.5" SATA drive bays2 M-key (PCIe4.0 x4 or SATA 6Gb/s), 22110/2280/2260/2242/2230 form factor |
| Networking | 2 RJ45 (1GbE)1 dedicated IPMI |
| Power | 1+1, 1000W PSU |
| Cooling | 6 PWM Easy-swap 40x56 mm fans |
| Dimensions (D × W × H) | 930 x 438 x 43.5 (36.6" x 17.2" x 1.7") |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
