S-SERIES · STORAGE
GL-S1U-12H
12 × 3.5″ HDD
1U storage server with 12 × 3.5″ HDD bays. Host platform: AMD EPYC 7002/7003. Validated with GenesysBench™ and deployed under GLIDS.
- Memory
- 8 DIMM slots
- Drive bays
- 12× 3.5″ HDD
- Height
- 1U
- Sockets
- 1
Specifications
Pick the host platform. The chassis, power and cooling follow it.
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 1U Rackmount |
|---|---|
| Processor | Single Socket SP3(LGA4094) Supports AMD EPYC™ 7002/7001 Series Processors |
| Memory | 8 DIMM Slots, Supports Eight-Channel DDR4 3200/2933/2666/2400 R DIMM (Modules up to 64GB Supported), and LR DIMM (Modules up to 256GB Supported) |
| Storage | 2 Hot-swap 2.5" SATA drive bays [Front]12 Hot-swap 2.5" or 3.5" SATA/SAS drive bays1 M-key (PCIe3.0 x4 or SATA 6Gb/s), 2280/2260/2242/2230 form factor1 M-key (PCIe3.0 x4 or SATA 6Gb/s), 22110/2280/2260/2242/ 2230 form factor |
| Networking | 10000/1000/100/10 Mbps2 x RJ45 10GLAN 1 x RJ45 Dedicated IPMI LAN Port |
| Power | 1U, Redundant700W |
| Cooling | 6 x 40*28 mm System Fans B-08 |
| Dimensions (D × W × H) | 860 x 438.5 x 43.2 mm (33.9" x 17.2" x 1.7") |
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 1U Rackmount |
|---|---|
| Processor | Single Socket SP3(LGA4094) Supports AMD EPYC™ 7002/7001 Series Processors |
| Memory | 8 DIMM Slots, Supports Eight-Channel DDR4 3200/2933/2666/2400 R DIMM (Modules up to 64GB Supported), and LR DIMM (Modules up to 256GB Supported) |
| Storage | 2 Hot-swap 2.5" NVMe drive bays [Front]12 Hot-swap 2.5" or 3.5" SATA/SAS drive bays1 M-key (PCIe3.0 x4 or SATA 6Gb/s), 2280/2260/2242/2230 form factor1 M-key (PCIe3.0 x4 or SATA 6Gb/s), 22110/2280/2260/2242/ 2230 form factor |
| Networking | 10000/1000/100/10 Mbps2 x RJ45 10GLAN 1 x RJ45 Dedicated IPMI LAN Port |
| Power | 1U, Redundant700W |
| Cooling | 6 x 40*28 mm System Fans B-08 |
| Dimensions (D × W × H) | 860 x 438.5 x 43.2 mm (33.9" x 17.2" x 1.7") |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
