N-SERIES · MULTI-NODE

GL-N1U-2NG

2 nodes, one GPU each

1U multi-node server with 2 nodes and one GPU per node (2 nodes/U). One chassis, 3 host platforms: AMD EPYC 4005/4004, Intel Xeon E-2300/E-2400 and AMD EPYC 7002. Validated with GenesysBench™ and deployed under GLIDS.

Nodes: 2, 1 GPU each
Height: 1U
Sockets: 1

Configure this system Talk to a Solutions Architect

Specifications

Pick the host platform. The chassis, power and cooling follow it.

GL-N1U-2NG: AMD EPYC 4005/4004 specifications
Form factor	1U Rackmount
Processor	1 Socket AM5 (LGA 1718); AMD EPYC™ 4005/4004 and AMD Ryzen™ 9000/8000/7000 series processors
CPU TDP	Up to 120W
Expansion	1 FHFL dual-slot PCIe5.0 x16 or2 FHFL single-slot PCIe5.0 x8
Storage	1 M-key (PCIe4.0 x4); 2280 form factor
Power	1+1, 80-PLUS Platinum, 1600W CRPS
Cooling	8 PWM hot-swap 40x56 mm fans
Dimensions (D × W × H)	650 x 438 x 43.5 mm (25.6" x 17.2" x 1.7")
Management	Dedicated BMC (IPMI)

GL-N1U-2NG: Intel Xeon E-2300/E-2400 specifications
Form factor	1U Rackmount
Processor	Socket H5 (LGA1200) for Intel® Xeon® E-2300 and 10th Gen Intel® Pentium® Series Processors
Expansion	1 FH dual-slot PCIe4.0Note1 x16
Storage	1 M-keyNote2 (PCIe4.0 x4); 2280 form factor1 M-key (PCIe3.0 x4); 2280 form factor
Networking	2 RJ45(10GbE)1 dedicated IPMI
Power	1+1 Platinum 1200W CRPS
Cooling	8 dual-rotor 40x56 mm fans
Dimensions (D × W × H)	650 x 438 x 43.5 mm (25.6'' x 17.2'' x 1.7'')

Previous generation. Still supported by GLabs; ask a solutions architect about availability.

GL-N1U-2NG: AMD EPYC 7002 specifications
Form factor	1U Rackmount
Processor	1 Socket SP3 (LGA4094), AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology )/7002 series processors
Expansion	1 FH dual-slot PCIe4.0 x16
Storage	1 M-key (PCIe4.0 x4 or SATA 6Gb/s), 2280 form factor
Power	1+1, 80-PLUS Platinum, 1600W CRPS
Cooling	8 PWM 40x56 mm fans
Dimensions (D × W × H)	650 x 438 x 43.5 mm (25.6'' x 17.2'' x 1.7'')
