N-SERIES · MULTI-NODEOPEN RACK
GL-N1OU-1N
1 nodes · Open Rack
1OU multi-node server with 1 nodes for Open Rack (1 node/OU). Host platform: AMD EPYC 9005. Validated with GenesysBench™ and deployed under GLIDS.
- Nodes
- 1
- Height
- 1OU
- Sockets
- 2
Specifications
Full public specification.
| Form factor | 1OU, one-bay Shelf for Open Rack V2 |
|---|---|
| Processor | 1+1 Socket SP5 (LGA 6096); AMD EPYC™ 9005/9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors |
| CPU TDP | Up to 400W |
| Storage | 1 OCP NIC 3.0 (PCIe5.0 x16)1 easy-swap 2.5" NVMe (PCIe5.0 x4) drive bay1 M-key (PCIe3.0 x4), 2280/2260/2242/2230 form factor1 M-key (PCIe3.0 x4), 2280/2242 form factor |
| Power | 1 IT Gear connector for ORv2 54V busbarCentralized 54V busbar to , distributed up to 2600W |
| Cooling | 8 easy-swap 40x56 mm fans |
| Dimensions (D × W × H) | 537 x 800 x 45.5 mm (D/W/H, Shelf Dimensions) |
| Management | Dedicated BMC (IPMI) TPM (13-pin, SPI) accessory |
Exact CPU, memory, drive and network parts are fixed on your quote. Open Rack sleds use the OU height unit. GPU and platform names are trademarks of their respective owners.
