G-SERIES · SCALE-OUT GPU

GL-G1U-1G4F

Up to 1 GPU · 4 NVMe

1U scale-out GPU server for up to 1 PCIe GPU and 4 NVMe bays. One chassis, 2 host platforms: Intel Xeon 6 and AMD EPYC 9005. Validated with GenesysBench™ and deployed under GLIDS; AI workloads run on the GLabs AI Stack.

GPUs: up to 1
Memory: 8 DIMM slots
Height: 1U
Sockets: 1

Configure this system Talk to a Solutions Architect

GL-G1U-1G4F, scale-out gpu server, overview

Specifications

Pick the host platform. The chassis, power and cooling follow it.

GL-G1U-1G4F: Intel Xeon 6 specifications
Form factor	1U Rackmount
Processor	1 Socket E2 (LGA 4710); Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors
Memory	8 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB (2Rx4) each, max. 6400MT/sRDIMM-3DS up to 256GB (4Rx4) each, max. 6400MT/sMRDIMM up to 64GB (2Rx4) each, max. 8000MT/s
Expansion	1 FHFL dual-slot PCIe5.0 x161 HHHL single-slot PCIe5.0 x16 1 OCP NIC 3.0 (PCIe5.0 x16)
Storage	4 hot-swap E1.S (PCIe5.0 x4) drive bays(PCIe5.0 / CXL2.0 x4); 2280 form factor (PCIe5.0 / CXL2.0 x4); 22110 form factor
Networking	1 dedicated IPMI
Power	1+1, 80-PLUS Titanium, 1600W CRPS
Cooling	9 PWM hot-swap 40x56 mm fans1 PWM hot-swap 40x28 mm fan
Dimensions (D × W × H)	650 x 438.0 x 43.5 mm (25.6" x 17.2" x 1.7")
Management	Dedicated BMC (IPMI)

GL-G1U-1G4F: AMD EPYC 9005 specifications
Form factor	1U Rackmount
Processor	1 Socket SP5 (LGA 6096); 97x4 series processors
CPU TDP	Up to 400W
Memory	8 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB each, max. 6400MT/sRDIMM-3DS up to 256GB each, max. 6400MT/s
Expansion	1 FHFL dual-slot PCIe5.0 x161 HHHL single-slot PCIe5.0 x16 1 OCP NIC 3.0 (PCIe5.0 x16)
Storage	4 hot-swap E1.S (PCIe5.0 x4) drive bays2 M-key (PCIe5.0 x4 or SATA 6Gb/s); support 22110/2280 form factor
Networking	1 dedicated IPMI
Power	1+1, 80-PLUS Titanium, 2000W CRPS
Cooling	9 PWM dual-rotor 40x56 mm fans1 PWM single-rotor 40x28 mm fan
Dimensions (D × W × H)	650 x 438 x 43.5 mm (25.6" x 17.2" x 1.7")
Management	Dedicated BMC (IPMI)
