C-SERIES · GENERAL PURPOSE
GL-C2U-2F
2 × NVMe
2U general-purpose server with 2 × NVMe bays. Host platform: Intel Xeon 6. Validated with GenesysBench™ and deployed under GLIDS.
- Drive bays
- 2× NVMe
- Height
- 2U
- Sockets
- 2
Specifications
Full public specification.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1+1 Socket E2 (LGA 4710) Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors |
| Expansion | 5 HHHL single-slot PCIe5.0 x16 |
| Storage | 2 Hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays2 M-key (PCIe5.0 x2), 22110/2280 form factor |
| Networking | 2 RJ45 (10GbE)1 dedicated IPMI |
| Power | 1+1, 80-PLUS Platinum, 1600W CRPS |
| Cooling | 4 PWM Hot-swap 80x56 mm fans1 PWM fixed 40x28 mm fan |
| Dimensions (D × W × H) | 580 x 438 x 87 mm (22.8" x 17.2" x 3.4") |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
