C-SERIES · GENERAL PURPOSEFRONT I/O
GL-C1U-2S-FIO
2 × 2.5″ SATA/SAS
1U general-purpose server with 2 × 2.5″ SATA/SAS bays, front I/O. Host platform: Intel Xeon 6300. Validated with GenesysBench™ and deployed under GLIDS.
- Drive bays
- 2× 2.5″ SATA/SAS
- Height
- 1U
- Sockets
- 1
Specifications
Full public specification.
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 socket LGA 1700; Intel® Xeon® 6300-series, Xeon® E-2400 series, and Pentium® Gold G7400/G7400T processors |
| Expansion | 1 FHHL PCIe5.0 x16 |
| Storage | 2 Pxed 2.5'' SATA (7mm) drive bays |
| Power | 1+1, 80-PLUS Platinum, 450W RPSU |
| Cooling | 3 PWM 40x56 mm dual-rotor fans |
| Dimensions (D × W × H) | 365.9 x 430 x 43.5mm (14.41'' x 16.93'' x 1.71'') |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
