C-SERIES · GENERAL PURPOSEREDUNDANT POWER SUPPLIES
GL-C1U-4H-R
4 × 3.5″ HDD
1U general-purpose server with 4 × 3.5″ HDD bays, redundant power. One chassis, 2 host platforms: AMD EPYC 4005/4004 and Intel Xeon 6300. Validated with GenesysBench™ and deployed under GLIDS.
- Drive bays
- 4× 3.5″ HDD
- Height
- 1U
- Sockets
- 1
Specifications
Pick the host platform. The chassis, power and cooling follow it.
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 Socket AM5 (LGA1718); Supports AMD EPYC™ 4005/4004 and AMD Ryzen™ 9000/8000/7000 Series Processors |
| Expansion | 1 FHHL PCIe4.0 x16 |
| Storage | 4 Hot-swap 3.5" SATA drive bays(PCIe5.0 x4), 2280/2242 form factor2 hot-swap 2.5" NVMe (PCIe4.0 x4) or 3.5" SATA 2 hot-swap 3.5" SATA drive bays(PCIe5.0 x4), 2280/2242 form factor (PCIe4.0 x4), 2280/2242 form |
| Networking | 2 RJ45 (10GbE)2 RJ45 (1GbE)1 dedicated IPMI |
| Power | 1+1, 450W PSU1+1, 80-PLUS Platinum, 650W Slim PSU |
| Cooling | 5 PWM Hot-swap 40x28 mm fans6 PWM Hot-swap 40x56 mm fans |
| Dimensions (D × W × H) | 533.4 x 438 x 44.4 mm (21" x 17.2" x 1.75")676.5 x 438 x 43.4 mm (26.6" x 17.2" x 1.7") |
| Management | Dedicated BMC (IPMI) TPM (13-pin, SPI) accessory General Purpose Server with Redundant PSU Supporting up to 2 Gen4 NVMe and 2 SATA TraysDedicated BMC (IPMI) TPM (13-pin, SPI) accessory |
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 Socket AM5 (LGA1718); Supports AMD EPYC™ 4005/4004 and AMD Ryzen™ 9000/8000/7000 Series Processors |
| Expansion | 1 FHHL PCIe4.0 x16 |
| Storage | 4 Hot-swap 3.5" SATA drive bays(PCIe5.0 x4), 2280/2242 form factor (PCIe4.0 x4), 2280/2242 form factordrive bays2 hot-swap 3.5" SATA drive baysfactor |
| Networking | 2 RJ45 (1GbE)1 dedicated IPMI 1 dedicated IPMI1 dedicated IPMI |
| Power | 1+1, 450W PSU1+1, 80-PLUS Platinum, 650W Slim PSU |
| Cooling | 5 PWM Hot-swap 40x28 mm fans6 PWM Hot-swap 40x56 mm fans |
| Dimensions (D × W × H) | 533.4 x 438 x 44.4 mm (21" x 17.2" x 1.75")676.5 x 438 x 43.4 mm (26.6" x 17.2" x 1.7") |
| Management | Dedicated BMC (IPMI) TPM (13-pin, SPI) accessory General Purpose Server with Redundant PSU Supporting up to 2 Gen4 NVMe and 2 SATA TraysDedicated BMC (IPMI) TPM (13-pin, SPI) accessory |
| Form factor | 1U Rackmount |
|---|---|
| Processor | 1 socket LGA 1700; Supports Intel® Xeon® 6300-series, Xeon® |
| Expansion | 1 FHHL PCIe5.0 x16 |
| Storage | 4 Hot-swap 3.5" SATA drive bays2 Pxed 2.5" NVMe (PCIe4.0 x4) drive bay1 M-key (PCIe4.0 x4); support 2280/2260/2242/2230 form factor |
| Networking | 2 RJ45 (10GbE)2 RJ45 (1GbE)1 dedicated IPMI |
| Power | 1+1, 80-PLUS Platinum, 450W RPSU |
| Cooling | 5 PWM Easy-swap 40x28 mm fans |
| Dimensions (D × W × H) | 533.4 x 482.6 x 44.4 mm (21” x 19” x 1.75”) |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
