X-SERIES · SCALE-UP GPULIQUID-COOLED
GL-X2U-RUBIN-L
NVIDIA HGX Rubin, liquid-cooled
2U scale-up GPU server on NVIDIA HGX Rubin, liquid-cooled. Host platform: Intel Xeon 6. Validated with GenesysBench™ and deployed under GLIDS; AI workloads run on the GLabs AI Stack.
- Platform
- HGX Rubin
- GPUs
- 8
- Memory
- 32 DIMM slots
- Height
- 2U
Specifications
Full public specification.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1+1 Socket E2 (LGA 4710); Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors |
| Memory | 16+16 DDR5 DIMM Slots (2DPC); RDIMM up to 128GB (2Rx4) each, max. 6400MT/s (1DPC), 5200MT/s (2DPC)RDIMM-3DS up to 256GB (4Rx4) each, max. 6400MT/s (1DPC), 5200MT/s (2DPC)MRDIMM up to 64GB (2Rx4) each, max. 8000MT/s (1DPC) |
| GPU | NVIDIA HGX™ Rubin NVL8 |
| PCIe fabric | NVIDIA® ConnectX®-9 |
| Expansion | 1 FHHL PCIe6.0 x16 |
| Storage | 8 hot-swap E1.S NVMe (PCIe6.0 x4) drive bays2 M-key (PCIe5.0 x4), support 2280 form factor |
| Networking | 8 OSFP (800Gb/s) ports® ConnectX®-9 |
| Power | 54V DC Busbar |
| Cooling | Direct-to-chip single-phase liquid cooling |
| Dimensions (D × W × H) | 800 x 448 x 87 mm (31.5" x 17.6" x 3.4") |
| Management | Dedicated BMC (IPMI) |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
