N-SERIES · MULTI-NODEOPEN RACK
GL-N2OU-3NG
3 nodes, one GPU each · Open Rack
2OU multi-node server with 3 nodes and one GPU per node for Open Rack (1.5 nodes/OU). Host platform: AMD EPYC 9005. Validated with GenesysBench™ and deployed under GLIDS.
- Nodes
- 3, 1 GPU each
- Height
- 2OU
- Sockets
- 1
Specifications
Full public specification.
| Form factor | 2OU, three-bay Shelf for Open Rack V3 |
|---|---|
| Processor | 1 Socket SP5 (LGA6096); AMD EPYC™ 9005/9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors |
| CPU TDP | Up to 400W |
| Memory | 8 DDR5 288-pin (1DPC); RDIMM up to 128GB each, max. 6400MT/sRDIMM-3DS up to 256GB each, max. 6400MT/s |
| GPU | 1 GPU or accelerator card up to 600W TDP at 25°C ambient or 300W at 35°C ambient |
| Expansion | 1 HHHL PCIe5.0 x16 1 OCP NIC 3.0 (PCIe5.0 x16) |
| Storage | 1 FHFL dual-slot PCIe5.0 x164 hot-swap E1.S (PCIe5.0 x4) drive bays2 M-key (PCIe5.0 x4 or SATA 6Gb/s), support 22110/2280 form factor |
| Power | Centralized 50/48V busbar, distributing up to 3200W per sled |
| Cooling | 2 system fans (80 x 38 mm) |
| Dimensions (D × W × H) | 537 x 803 x 93 mm (21.1" x 31.6" x 3.7", shelf dimensions) |
| Management | Dedicated BMC (IPMI) TPM (13-pin, SPI) |
Exact CPU, memory, drive and network parts are fixed on your quote. Open Rack sleds use the OU height unit. GPU and platform names are trademarks of their respective owners.
