GL-G2U-4G
Up to 4 GPUs
2U scale-out GPU server for up to 4 PCIe GPUs. One chassis, 4 host platforms: AMD EPYC 9005, AMD EPYC 9004, AMD EPYC 7002 and AMD EPYC 7002/7003. Validated with GenesysBench™ and deployed under GLIDS; AI workloads run on the GLabs AI Stack.
- GPUs
- up to 4
- Memory
- 8 DIMM slots
- NVMe bays
- 4×
- Height
- 2U
Specifications
Pick the host platform. The chassis, power and cooling follow it.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket SP5 (LGA 6096); AMD EPYC™ 9005/9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors |
| CPU TDP | Up to 400W |
| Memory | 8 DIMM slots (1DPC) |
| Expansion | 4 FHFL dual-slot PCIe5.0 x16 |
| Storage | 4 hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays2 M-key (PCIe5.0 x4), support 22110/2280 form factor |
| Networking | 1 dedicated IPMI |
| Power | 1+1, 80-PLUS Titanium, 2700W CRPS |
| Cooling | 3 PWM fixed 80x38 mm fans, 1 PWM fixed 80x80 mm fan |
| Dimensions (D × W × H) | 850 x 438 x 87.5 mm (33.5" x 17.2" x 3.4") |
| Management | Dedicated BMC (IPMI) |
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket SP5 (LGA 6096); AMD EPYC™ 9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors |
| CPU TDP | Up to 360W |
| Memory | 8 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB each, max. 5200MT/sRDIMM-3DS up to 256GB each, max. 5200MT/s |
| Expansion | 3 FHFL dual-slot PCIe5.0 x161 FHFL dual-slot PCIe5.0 x16 1 OCP NIC 3.0 PCIe5.0 x161 FHHL PCIe5.0 x161 FHFL PCIe5.0 x8 |
| Storage | 4 hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays2 M-key (PCIe5.0 x4 or SATA 6Gb/s); support 22110/2280 form factor |
| Networking | 1 dedicated IPMI |
| Power | 1+1, 80-PLUS Platinum, 2700W CRPS |
| Cooling | 1 PWM hot-swap 80x80 mm fan3 PWM hot-swap 80x38 mm fans |
| Dimensions (D × W × H) | 850 x 438 x 87.5 mm (33.5" x 17.2" x 3.5") |
| Management | Dedicated BMC (IPMI) |
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket SP3(LGA4094), AMD EPYC™ 7003 (with AMD 3D V-Cache™ Technology )/7002 series processors |
| Memory | 8 DIMM Slots, Supports Eight-Channel DDR4 3200/2933 R DIMM (Modules up to 64GB Supported), and LR DIMM (Modules up to 256GB Supported) |
| Storage | 3 Hot-swap 2.5" SATA drive bays [Front]1 Hot-swap 2.5" NVMe drive bay [Front] 1 Hot-swap 2.5" NVMe/SATA drive bay [Front] 1 M-key (PCIe3.0 x4 or SATA 6Gb/s), 2280/2260/2242/2230 form factor |
| Networking | 10000/1000/100/10 Mbps2 x RJ45 10GLAN 1 x RJ45 Dedicated IPMI LAN port |
| Power | 2(1+1)2000W, 80-PLUS Platinum |
| Cooling | 6 x 80*38mm System Fans |
| Dimensions (D × W × H) | 795 x 438 x 87.5 mm (31.3" x 17.2" x 3.4") |
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 2U Rackmount |
|---|---|
| Storage | 4 x 2.5" SATA 6GB/s HDDs (1 x SATA3 HDD could |
| Networking | RJ45:2(10G)+1(IPMI) |
| Power | 1+1 Redundant2000W, 80-PLUS Platinum |
| Cooling | 6 x 80*38mm System Fans B-16 |
| Dimensions (D × W × H) | 795 x 438 x 87.5 mm (31.3" x 17.2" x 3.4") |
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 2U Rackmount |
|---|---|
| Storage | support NVMe or SATA3 6GB/s HDDs) + 1 x NVMe |
| Networking | RJ45:2(1G)+1(IPMI) |
| Power | 1+1 Redundant2000W, 80-PLUS Platinum |
| Cooling | 6 x 80*38mm System Fans B-16 |
| Dimensions (D × W × H) | 795 x 438 x 87.5 mm (31.3" x 17.2" x 3.4") |
NVIDIA-Qualified GPUs
- NVIDIA L40S · on AMD EPYC 9004
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
