G-SERIES · SCALE-OUT GPU
GL-G2U-2G
Up to 2 GPUs
2U scale-out GPU server for up to 2 PCIe GPUs. One chassis, 4 host platforms: Intel Xeon 6, AMD EPYC 9005, AMD EPYC 9004 and 3rd Gen Intel Xeon. Validated with GenesysBench™ and deployed under GLIDS; AI workloads run on the GLabs AI Stack.
- GPUs
- up to 2
- Memory
- 8 DIMM slots
- NVMe bays
- 2×
- Height
- 2U
Specifications
Pick the host platform. The chassis, power and cooling follow it.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket E2 (LGA 4710); Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors |
| CPU TDP | Up to 350W |
| Memory | 8 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB (2Rx4) each, max. 6400MT/sRDIMM-3DS up to 256GB (4Rx4) each, max. 6400MT/sMRDIMM up to 64GB (2Rx4) each, max. 8000MT/s |
| Expansion | 2 FHFL dual-slot PCIe5.0 x16 |
| Storage | 2 hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays2 M-key (PCIe5.0 x4); support 2280 form factor |
| Networking | 1 dedicated IPMI |
| Power | 1+1, 80-PLUS Titanium, 2700W CRPS |
| Cooling | Front: 4 PWM hot-swap 80x56 mm fans, Middle: 1 PWM fixed 40x28 mm fan |
| Dimensions (D × W × H) | 580 x 438 x 87 mm (22.8" x 17.2" x 3.4") |
| Management | Dedicated BMC (IPMI) |
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket E2 (LGA 4710); Intel® Xeon® 6700P-series, 6500P-series, and 6700E-series processors |
| CPU TDP | Up to 350W |
| Memory | 8 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB (2Rx4) each, max. 6400MT/sRDIMM-3DS up to 256GB (4Rx4) each, max. 6400MT/sMRDIMM up to 64GB (2Rx4) each, max. 8000MT/s |
| Expansion | 2 FHFL dual-slot PCIe5.0 x16 |
| Storage | 2 hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays2 M-key (PCIe5.0 x4); support 2280 form factor |
| Networking | 1 dedicated IPMI |
| Power | 1+1, 80-PLUS Titanium, 2000W CRPS |
| Cooling | Front: 4 PWM hot-swap 80x56 mm fans, Middle: 1 PWM fixed 40x28 mm fan |
| Dimensions (D × W × H) | 580 x 438 x 87 mm (22.8" x 17.2" x 3.4") |
| Management | Dedicated BMC (IPMI) |
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket SP5 (LGA 6096P); AMD EPYC™ 9005/9004 (with AMD 3D V-Cache™ Technology) and |
| CPU TDP | Up to 500W |
| Memory | 12 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB each, max. 6400MT/sRDIMM-3DS up to 256GB each, max. 6400MT/s |
| Expansion | 2 FHFL dual-slot PCIe5.0 x16 |
| Storage | 2 hot-swap 2.5" NVMe (PCIe4.0 x4) drive bays2 M-key (PCIe5.0 x4 or 4 SATA 6Gb/s); support 22110/2280/2260 form |
| Networking | 1 dedicated IPMI |
| Power | 1+1, 80-PLUS Titanium, 2700W CRPS |
| Cooling | 4 PWM hot-swap 80x56 mm fans1 PWM fixed 40x28 mm fan |
| Dimensions (D × W × H) | 580 x 438 x 87 mm (22.8" x 17.2" x 3.4") |
| Management | Dedicated BMC (IPMI) |
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket SP5 (LGA 6096P); 97x4 series processors |
| CPU TDP | Up to 500W |
| Memory | 12 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB each, max. 6400MT/sRDIMM-3DS up to 256GB each, max. 6400MT/s |
| Expansion | 2 FHFL dual-slot PCIe5.0 x16 |
| Storage | 2 hot-swap 2.5" NVMe (PCIe4.0 x4) drive baysfactor |
| Networking | 1 dedicated IPMI |
| Power | 1+1, 80-PLUS Titanium, 2000W CRPS |
| Cooling | 4 PWM hot-swap 80x56 mm fans1 PWM fixed 40x28 mm fan |
| Dimensions (D × W × H) | 580 x 438 x 87 mm (22.8" x 17.2" x 3.4") |
| Management | Dedicated BMC (IPMI) |
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1 Socket SP5 (LGA 6096); AMD EPYC™ 9005/9004 (with AMD 3D V-Cache™ Technology) and 97x4 series processors |
| Memory | 12 DDR5 DIMM Slots (1DPC); RDIMM up to 128GB each, max. 5200MT/sRDIMM-3DS up to 256GB each, max. 5200MT/s |
| Expansion | 2 FHFL dual-slot PCIe5.0 x162 HHHL single-slot PCIe5.0 x16 1 OCP NIC 3.0 (PCIe5.0 x16) |
| Storage | 2 M-key (PCIe5.0 x4 or SATA 6Gb/s); support 22110/2280/2260 form factor |
| Networking | 1 dedicated IPMI |
| Power | 1+1, 80-PLUS Titanium, 2000W CRPS |
| Cooling | Front: 4 PWM hot-swap 80x56 mm fans Middle: 1 PWM fixed 40x28 mm fan |
| Dimensions (D × W × H) | 580 x 438 x 87 mm (22.8" x 17.2" x 3.4") |
| Management | Dedicated BMC (IPMI) |
Previous generation. Still supported by GLabs; ask a solutions architect about availability.
| Form factor | 2U Rackmount |
|---|---|
| Processor | 1+1 Socket P+ (LGA4189) for 3rd Gen Intel® Xeon® Scalable Processors |
| Expansion | SLOT1: 1 FHFL PCIe4.0 x16Note1, 1 FHHL PCIe4.0 x16- SLOT2: 1 FHFL PCIe4.0 x16Note1, 1 FHHL PCIe4.0 x16- SLOT3: 1 low-profile PCIe4.0 x16 or 2 low-profile PCIe4.0 x8- |
| Storage | 12 Hot-swap 3.5"/2.5" drive bays, 8 SATA HDD/SSD and 4 NVMe (PCIe4.0 x4) SSD2 Qxed 2.5" SATA drive bays2 M-keyNote2 (PCIe3.0 x4 or SATA 6Gb/s), 22110/2280 form factor |
| Networking | 2 RJ45 (1GbE)1 dedicated IPMI |
| Power | 1+1 2000W CRPS |
| Cooling | 6 PWM Hot-swap 60x38 mm fans |
| Dimensions (D × W × H) | 779.5 x 447.6 x 87 mm (30.69'' x 17.62'' x 3.43'') |
Exact CPU, memory, drive and network parts are fixed on your quote. GPU and platform names are trademarks of their respective owners.
Views
Configure GL-G2U-2G
Choose the host, memory, storage and networking. Your request goes straight to a Solutions Architect, who replies with a validated build and quote.
- 01System and host
- 02Processor
- 03Memory
- 04GPU
- 05Storage
- 06Networking
- 07Software stack
- 08Send request
Tell us what you're building.
A solutions architect responds directly — no ticket queue.
